Provide High Performance 360°
Rotary Solutions for Worldwide
| Specifications of Rotating Slip Rings | ||||
| Mechanical data | Electrical data | |||
| Parameter | Value | Parameter | Value | |
| Working Life | 100 Million Revs | Power | Signal | |
| Rotating Speed | 1~1800RPM | Rated Voltage | 0~690VAC/VDC | 0~440VAC/VDC |
| Working Temp. | -30℃~80℃ | Insulation Res | ≥1000MΩ/500VDC | ≥1000MΩ/500VDC |
| Operating Humidity | 0~85% RH | Lead Wires | AWG16#Teflon | AWG22#Teflon |
| Contact Material | Precious Metal | Lead Length | Standard 300mm | |
| Housing Material | Aluminium Alloy | Dielectric Strength | 1000VAC@50Hz，60s | |
| Torque | 0.1N.m;+0.03/6ring | Res Noise | <0.03Ω | |
| Protection grade | IP51 | |||
Note: Power 10A and signal(5A) can combine freely, please contact customer service for more details. Our slip rings can be customized on the basis of standard slip rings. Should contact customer service for more information. What is rotating sip rings and electrical rotating connector? A special electrical connector which can get power/signal passed from stationary part to rotating part when 360°continually rotating, at the same time, all electrical wires is not twisted. moflon supply full range of sip rings and electrical rotating connectors for automated welding equipment,conveyor systems,custom machinery,fabrication equipment,food processing machinery,injection presses,intelligent machinery,laminating equipment,machine tools,manipulators, electric,material handling systems,packaging machinery,pallet wrappers,paper processing machinery,plating machinery. (see our website http://www.moflon.com/contact.html)or send an email to sales@moflon.com | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
